It is widely used in car rental, fleet management, and logistics.
It supports remote power cutoff to protect your vehicle at all times.
Product Description
BSJ Technology's vehicle GPS tracker and vehicle tracking GPS device are the ultimate tools for efficient vehicle tracking and fleet management. Our advanced technology provides real-time location data, enabling you to monitor your vehicles' speed and route, and ensuring optimal fleet performance and safety. Our vehicle tracking fleet management system streamlines your operations, reduces operating costs, and improves customer satisfaction. Trust BSJ Technology to provide you with the most reliable and innovative vehicle tracking solutions on the market.
Product Features
 | Real-time TrackingUpload the longitude and latitude information according to the time interval |  | Upload Blind DataThe device will store location data in the network blind area, and upload this data when the GSM signal is good. |
 | Upload Inflection DataWhen the direction angle of the device changes by more than a certain angle, one location data will be uploaded immediately to optimize the trajectory. |  | Power Off AlarmTurn on the backup battery, when the vehicle voltage is lower than 5v, the device uploads an alarm to the server |
 | Remote Upgrade The device supports updating firmware versions remotely. |  | Over-speed Alarm Set the maximum speed limit value through the platform or SMS command. When the GPS speed exceeds the set value, the device will upload an alarm to the server |
 | Basic Driving Behavior MonitoringSupport uploading rapid acceleration alarm, rapid deceleration alarm, sharp turns alarm, collision alarm, and vibration alarm to the server |  | SMS QuerySend “WHERE#” through SMS or platform to get latitude and longitude, current time, speed, ACC status, and Google Maps link. |
 | Listen-inDial the SIM card number in the device from the mobile phone, you can directly listen to the sounds around the car |  | SOS Alarm In case of an emergency, the SOS alarm can be triggered and reported to the platform through the SOS button |
 | ACC On/Off StatusUploaded location data with the ACC on/off status each time |  | Fuel Cut OffCut off/supply fuel remotely through server or SMS |
Product Specification
| GPS | ||
| GPS Channels | 22 Channels For Tracking, 66 Channels For Acquisition | |
| GPS Frequency | 1575.42MHz | |
GPS Ceramic Antenna | 25*25*4MM | |
| Tracking Sensitivity | -160dBm | |
| Acquisition Sensitivity | -147dBm |
| GSM | ||
| Communication System | GSM | |
Band | 850/900/1800/1900MHz | |
| GPRS | Class 12, TCP/IP | |
| Maximum Output Power | GSM850/GSM900：32.5±2dBm, GSM1800/GSM1900:30±2dBm | |
| Receiving Sensitivity | ClassII RBER2%(-103dBm) | |
| Communication Antenna | Built-in on-board FPC Antenna |
| Other | ||
| Antenna | Built-in GPS ceramic antenna, built-in on-board communication FPC Antenna | |
| LED Indicator | GPS: Yellow；GSM: Red | |
| Standby Battery | About 3 hours (3.7V 300mAh Soft Pack Lithium Battery) | |
| Working Voltage | DC 9V - 90 V | |
Working Current | 80mA @12V(static current3mA) | |
Dimension | 84mm*42mm*13.6mm | |
Power Cable | 8 Pin （Power+, GND, ACC, Fuel, Listen-in, SOS） | |
Motion Sensor | DA213 |
Application Description
A vehicle GPS tracker is an essential tool for fleet management companies looking to improve their operations. By using a vehicle tracking GPS device, fleet managers can keep track of the whereabouts of their vehicles in real-time. This helps them optimize their routes and manage their fleets more efficiently, leading to reduced fuel costs and improved productivity.
For instance, a delivery company can use a vehicle GPS tracker to monitor the location and movement of its delivery trucks. By doing so, they can identify which routes are the most efficient and make adjustments to optimize their delivery schedules. In addition, if a truck experiences any delays or issues on the road, the company can quickly dispatch assistance to the location thanks to the real-time tracking provided by the GPS device.
Overall, a vehicle tracking system that incorporates a GPS tracker can provide fleet managers with valuable data to help them make informed decisions about their operations. Whether it's optimizing routes, reducing fuel costs, or improving driver safety, the benefits of using a vehicle GPS tracker are clear.
