Product Description

Introducing the BSJ Technology GPS vehicle tracking device - your all-in-one solution for enhanced vehicle security and real-time monitoring. Our device is designed to provide you with accurate and reliable location data, speed tracking, and other important metrics to help you stay informed and in control of your ride.

With our easy-to-install and user-friendly tracking device, you can keep a close eye on your vehicle's whereabouts at all times, no matter where you are. Whether you're looking to optimize your fleet management or ensure the safety of your loved ones on the road, our GPS tracking device offers a range of features and benefits to help you achieve your goals.

Our device is equipped with advanced GPS technology, allowing you to track your vehicle's location with pinpoint accuracy. You can also set up custom alerts and notifications for events such as speeding, geofencing, and more, giving you real-time updates and peace of mind.

At BSJ Technology, we understand the importance of vehicle security and monitoring. That's why our GPS tracking device is built to withstand even the harshest conditions and provide you with reliable data whenever you need it. With our affordable and feature-packed tracking solution, you can take control of your ride and stay ahead of the curve.

Product Features



	Real-time Tracking Upload the longitude and latitude information according to the time interval		Upload Blind Data The device will store location data in the network blind area, and upload this data when the GSM signal is good.
	Upload Inflection Data When the direction angle of the device changes by more than a certain angle, one location data will be uploaded immediately to optimize the trajectory.		Power Off Alarm Turn on the backup battery, when the vehicle voltage is lower than 5v, the device uploads an alarm to the server
	Remote Upgrade The device supports updating firmware versions remotely.		Over-speed Alarm Set the maximum speed limit value through the platform or SMS command. When the GPS speed exceeds the set value, the device will upload an alarm to the server
	Basic Driving Behavior Monitoring Support uploading rapid acceleration alarm, rapid deceleration alarm, sharp turns alarm, collision alarm, and vibration alarm to the server		SMS Query Send “WHERE#” through SMS or platform to get latitude and longitude, current time, speed, ACC status, and Google Maps link.
	ACC On/Off Status Uploaded location data with the ACC on/off status each time		Fuel Cut Off Cut off/supply fuel remotely through server or SMS



Specification



GPS
	GPS Channels	22 Channels For Tracking, 66 Channels For Acquisition
	GPS Frequency	1575.42MHz
	GPS Ceramic Antenna	18*18*2MM
	Tracking Sensitivity	-160dBm
	Acquisition Sensitivity	-147dBm




GSM
	Communication System	GSM
	Band	850/900/1800/1900MHz
	GPRS	Class 12, TCP/IP
	Maximum Output Power	GSM850/GSM900：32.5±2dBm, GSM1800/GSM1900:30±2dBm
	Receiving Sensitivity	ClassII RBER2%(-103dBm)
	Communication Antenna	Built-in FPC Antenna 49.04*6.11*0.12(±0.2MM)



Other
	Antenna	Built-in GPS ceramic antenna, built-in communication FPC antenna
	LED Indicator	GPS: Yellow； GSM: Red
	Standby Battery	About 10min (3.7V 55mAh Soft Pack Lithium Battery)
	Working Voltage	DC 9V - 36 V
	Working Current	25mA@12V(Static Current 10mA)
	Dimension	L78.5mm*W23mm*H12mm
	Power Cable	4 Pin （Power+, GND, ACC, Fuel）
	Motion Sensor	DA213

Application Description

Imagine being able to track your entire fleet of vehicles in real-time, knowing exactly where each vehicle is, how fast it's going, and whether it's on schedule. With the BSJ Technology GPS vehicle tracking device, this is no longer just a dream, but a reality.

Our tracking device is ideal for a wide range of applications, including fleet management, logistics, and transportation. Whether you're running a small business with a few vehicles or managing a large fleet of trucks, our device provides you with the data you need to optimize your operations and improve your bottom line.

In addition to fleet management, our GPS tracking device is also useful for personal use, such as monitoring the driving habits of your teenage children or elderly parents. You can set up custom alerts for events such as speeding, sudden stops, and geofencing, giving you the peace of mind that comes with knowing your loved ones are safe on the road.

Overall, the BSJ Technology GPS vehicle tracking device is an essential tool for anyone looking to enhance vehicle security and monitoring. Whether you're a business owner, a concerned parent, or simply want to keep an eye on your personal vehicle, our device has got you covered.
