KM-01AXR is compact and lightweight, which easy for hidden installation,
Widely used in car rental, fleet management, and logistics.
It supports remote power cutoff to protect your vehicle at all times.
Product Description
BSJ Technology's motorcycle GPS tracker is the perfect solution for motorcycle owners who want to keep their bikes safe and secure. Our GPS tracking device for motorcycle provides real-time location tracking, so you can monitor your bike's movements and location at all times. The geo-fencing alerts and tamper-proof features will instantly notify you if your motorcycle is moved or tampered with without your permission.
Our motorcycle tracking device is easy to install and use, and it's compatible with most motorcycles. Once installed, you can access your bike's location and receive alerts through our user-friendly mobile app.
Investing in our motorcycle GPS tracker gives you peace of mind, knowing that your bike is protected from theft and loss. Don't wait until it's too late – safeguard your motorcycle with BSJ Technology's advanced GPS tracking device for motorcycle today.
Product Features
 | Real-time TrackingUpload the longitude and latitude information according to the time interval |  | Upload Blind DataThe device will store location data in the network blind area, and upload this data when the GSM signal is good. |
 | Upload Inflection DataWhen the direction angle of the device changes by more than a certain angle, one location data will be uploaded immediately to optimize the trajectory. |  | Power Off AlarmTurn on the backup battery, when the vehicle voltage is lower than 5v, the device uploads an alarm to the server |
 | Remote Upgrade The device supports updating firmware versions remotely. |  | Over-speed Alarm Set the maximum speed limit value through the platform or SMS command. When the GPS speed exceeds the set value, the device will upload an alarm to the server |
 | Basic Driving Behavior MonitoringSupport uploading rapid acceleration alarm, rapid deceleration alarm, sharp turns alarm, collision alarm, and vibration alarm to the server |  | SMS QuerySend “WHERE#” through SMS or platform to get latitude and longitude, current time, speed, ACC status, and Google Maps link. |
 | ACC On/Off StatusUploaded location data with the ACC on/off status each time |  | Fuel Cut OffCut off/supply fuel remotely through server or SMS |
Product Specification
| GPS | ||
| GPS Channels | 22 Channels For Tracking, 66 Channels For Acquisition | |
| GPS Frequency | 1575.42MHz | |
GPS Ceramic Antenna | 25*25*4MM | |
| Tracking Sensitivity | -160dBm | |
| Acquisition Sensitivity | -147dBm |
| GSM | ||
| Communication System | GSM | |
| Band | 850/900/1800/1900MHz | |
| GPRS | Class 12, TCP/IP | |
| Maximum Output Power | GSM850/GSM900：32.5±2dBm, GSM1800/GSM1900:30±2dBm | |
| Receiving Sensitivity | ClassII RBER2%(-103dBm) | |
| Communication Antenna | Built-in FPC Antenna 28.00*12.00*0.12(±0.2MM) |
| Other | ||
| Antenna | Built-in GPS ceramic antenna, built-in communication FPC antenna | |
| LED Indicator | GPS: Yellow； GSM: Red | |
| Standby Battery | 2-3 hours (3.7V/180mAh lithium battery) | |
| Working Voltage | DC 9V - 90 V | |
Working Current | 25mA @12V(static current10mA) | |
Dimension | L81*W42*H13.5mm | |
Power Cable | 4 Pin （Power+, GND, ACC, Fuel） | |
Motion Sensor | DA213 |
Imagine you're planning a long motorcycle trip through unknown territory. You've spent months planning the route and preparing your bike for the journey. But how do you ensure the safety of your beloved motorcycle on the road?
This is where BSJ Technology's motorcycle GPS tracker comes in. With our GPS tracking device for motorcycle, you can easily monitor your bike's location and movements throughout your trip. You can set up geo-fencing alerts to receive notifications if your motorcycle moves beyond a specific perimeter, giving you peace of mind knowing that your bike is safe and secure.
In the event that your motorcycle is stolen, our motorcycle tracking device enables you to immediately track its location and alert the authorities. With our tamper-proof features, you'll receive notifications if anyone tries to tamper with your bike's GPS tracker, making it harder for thieves to get away with your motorcycle.
Whether you're embarking on a long journey or simply want to protect your motorcycle while it's parked at home, BSJ Technology's motorcycle GPS tracker is the perfect solution for motorcycle owners looking to keep their bikes safe and secure.
