Product Features



	Real-time Tracking Upload the longitude and latitude information according to the time interval		Upload Data In Blind Area The device will store location data in network blind area, upload this data when the GSM signal is good.
	Upload Inflection Data When the direction angle of the device changes by more than a certain angle, one location data will be uploaded immediately to optimize the trajector.		Power Off Alarm Turn on backup battery, when the vehicle voltage is lower than 5v, the device upload an alarm to the server
	Remote Upgrade The device supports update firmware version remotely.		Over-speed Alarm Set the maximum speed limit value through the platform or SMS command. When the GPS speed exceeds the set value, the device will upload an alarm to the server
	Basic Driving Behavior Monitoring Support uploading rapid acceleration alarm, rapid deceleration alarm, sharp turns alarm, collision alarm, vibration alarm to server		SMS Query Send “WHERE#” through SMS or platform to get latitude and longitude, current time, speed, ACC status, Google Maps link.
	ACC On/Off Status Uploaded location data with the ACC on/off status each time		Fuel Cut Off Cut off/supply fuel remotely through server or SMS



Specification



GPS
	GPS Channels	22 Channels For Tracking, 66 Channels For Acquisition
	GPS Frequency	GPS Frequency: 1575.42±2MHz；BD Frequency: 1561.098±2MHz
	GPS Ceramic Antenna	25*25*2MM
	Tracking Sensitivity	-165dBm
	Acquisition Sensitivity	-148dBm




GSM
	Communication System	TDD-LTE/FDD-LTE/GSM
	Band	GSM：900/1800MHz TDD-LTE：B34、B38、B39、B40、B41 FDD-LTE：B1、B3、B5、B8
	Maximum Output Power	GSM900 Class433±2dBm，GSM1800 Class130±2dBm LTE FDD: 23±2dBm, LTE TDD: 23±2dBm
	Receiving Sensitivity	GSM: (-109dBm)；LTE FDD: (-98dBm)；LTE TDD:  (-98dBm)
	Communication Antenna	Built-in FPC Antenna 61.43*18.3*0.12(±0.2MM)




Other
	Antenna	Built-in GPS ceramic antenna, built-in communication FPC antenna
	LED Indicator	GPS: Yellow；GSM: Red
	Standby Battery	10Min (3.7V/55mAh lithium battery)
	Working Voltage	DC 9V - 90 V
	Working Current	50mA@12V(Static Current 400uA)
	Dimension	77mm*45mm*12mm
	Power Cable	4 Pin （Power+, GND, ACC, Fuel）
	Motion Sensor	DA213
